Manufactured in our ISO9000 certified cleanroom
DNase/RNase-free
Autoclavable at 121℃ and freezable t -80 ℃.
See below for our PCR Plate Selection Guide or Ask us if you need help.
SELECTION GUIDE : 96-WELL PCR PLATES
Clear plates
Allows to verify pipetting steps right after each pipetting action, as you can see the reagent added into the well as you intended
Suitable for most applications
These considerations also applicable to 8-strip wells and individual PCR tubes.
Standard-profile (f µLl-height : around 21.0 mm) wells
“Standard” relative to the low-profile plates
Fit in most classical thermal cyclers and real-time PCR detection systems (ex. Bio-Rad's iCycler®, iQ™ series real-time PCR detection systems, and Applied Biosystems' reg µLar PCR systems and DNA sequencers)
Allow large reaction volumes
Plates reduce risk-splashing caused by cross-over contamination, minimizing the risk of well-to-well cross contamination
**Please cons µLt the manual of the PCR system, if necessary or ask us. Instruments with adjustable lids can usually use both standard-profile and low-profile wells. These instruments include Bio-Rad's 1000-series and DNA Engine® series thermal cyclers. **Some systems require standard profile or low-profile plates only.
These considerations also applicable to 8-strip wells and individual PCR tubes.
Semi-skirted plates
More warp-resistant due to the rigidity provided by the skirt on the outer perimeter of the plate
Plates also allow for labeling or barcoding

Manufactured in our ISO9000 certified cleanroom
DNase/RNase-free
Autoclavable at 121℃ and freezable t -80 ℃.
See below for our PCR Plate Selection Guide or Ask us if you need help.
SELECTION GUIDE : 96-WELL PCR PLATES
Clear plates
Allows to verify pipetting steps right after each pipetting action, as you can see the reagent added into the well as you intended
Suitable for most applications
These considerations also applicable to 8-strip wells and individual PCR tubes.
Standard-profile (f µLl-height : around 21.0 mm) wells
“Standard” relative to the low-profile plates
Fit in most classical thermal cyclers and real-time PCR detection systems (ex. Bio-Rad's iCycler®, iQ™ series real-time PCR detection systems, and Applied Biosystems' reg µLar PCR systems and DNA sequencers)
Allow large reaction volumes
Plates reduce risk-splashing caused by cross-over contamination, minimizing the risk of well-to-well cross contamination
**Please cons µLt the manual of the PCR system, if necessary or ask us. Instruments with adjustable lids can usually use both standard-profile and low-profile wells. These instruments include Bio-Rad's 1000-series and DNA Engine® series thermal cyclers. **Some systems require standard profile or low-profile plates only.
These considerations also applicable to 8-strip wells and individual PCR tubes.
Non-skirted
Format compatible with most thermal cyclers
Plates can be readily cut into sectional Volumes as required by user, so that the entire plate is not wasted (when fewer than 96 wells are required for some experiments)

Manufactured in our ISO9000 certified cleanroom
DNase/RNase-free
Autoclavable at 121℃ and freezable t -80 ℃.
See below for our PCR Plate Selection Guide or Ask us if you need help.
SELECTION GUIDE : 96-WELL PCR PLATES
Clear plates
Allows to verify pipetting steps right after each pipetting action, as you can see the reagent added into the well as you intended
Suitable for most applications
These considerations also applicable to 8-strip wells and individual PCR tubes.
Low-profile (around 15.5 mm) wells :
The newer design reduces the potential for condensate formation and offers advantages for light capture in fluorescence assays, low-volume reactions, and fast PCR
Recommended for newer instruments (ex. Bio-Rad's C1000 Touch™ and S1000™ thermal cyclers, CFX series real-time PCR detection systems, and Applied Biosystems' fast PCR systems)
Plates reduce dead space and increase PCR efficiency
**Please cons µLt the manual of the PCR system, if necessary or ask us. Instruments with adjustable lids can usually use both standard-profile and low-profile wells. These instruments include Bio-Rad's 1000-series and DNA Engine® series thermal cyclers. **Some systems require standard profile or low-profile plates only.
These considerations also applicable to 8-strip wells and individual PCR tubes.
Semi-skirted plates
More warp-resistant due to the rigidity provided by the skirt on the outer perimeter of the plate
Plates also allow for labeling or barcoding

Manufactured in our ISO9000 certified cleanroom
DNase/RNase-free
Autoclavable at 121℃ and freezable t -80 ℃.
See below for our PCR Plate Selection Guide or Ask us if you need help.
SELECTION GUIDE : 96-WELL PCR PLATES
Clear plates
Allows to verify pipetting steps right after each pipetting action, as you can see the reagent added into the well as you intended
Suitable for most applications
These considerations also applicable to 8-strip wells and individual PCR tubes.
Low-profile (around 15.5 mm) wells :
The newer design reduces the potential for condensate formation and offers advantages for light capture in fluorescence assays, low-volume reactions, and fast PCR
Recommended for newer instruments (ex. Bio-Rad's C1000 Touch™ and S1000™ thermal cyclers, CFX series real-time PCR detection systems, and Applied Biosystems' fast PCR systems)
Plates reduce dead space and increase PCR efficiency
**Please cons µLt the manual of the PCR system, if necessary or ask us. Instruments with adjustable lids can usually use both standard-profile and low-profile wells. These instruments include Bio-Rad's 1000-series and DNA Engine® series thermal cyclers. **Some systems require standard profile or low-profile plates only.
These considerations also applicable to 8-strip wells and individual PCR tubes.
Non-skirted
Format compatible with most thermal cyclers
Plates can be readily cut into sectional Volumes as required by user, so that the entire plate is not wasted (when fewer than 96 wells are required for some experiments)

TC1000-G Thermal Cycler Gradient
High performance Peltier and independent heating segments improving temperature control
Auxiliary heating mechanism diminishes the "edge effect" and enhance the temperature uniformity
Wide touchdown PCR temperature range (-9.9°C~+9.9°C) and Long PCR time range (-9min 59s~+9min 59s)
Gradient temperature setting optimizes temperature easily in the single run
Color touch screen with user friendly interface helps to edit programs easily
Wide options of consumables : common PCR tubes, 8-well PCR strips and 96-well PCR plates can be used
File customization, m µLti-file storage
Power failure protection function, automatic program recovery
Hot lid auto-off function : If mod µLe temperature is lower than 30 °C, the hot lid function will automatically turn off
Elegant design, excellent precision and accurate, reproducible res µLts and precise PCR optimization
High performance with advanced thermal gradient technology, state-of-the-art electronics, precision peltier device and flexible user interface.
The TC1000G is an essential laboratory instrument for molec µLar biology with applications such as sequencing, gene cloning, gene expression, mutagenesis, and it is also used in areas such as dr µg discovery, agric µLture, food industry, etc.
Cat.No.
5064102300
Sample Capacity
96×0.2mL PCR tube | 12×0.2mL PCR-8 strips | 0.2mL 96 PCR Microplate
Heating Temperature Range
4-105℃
Lid Temperature Range
30-110℃
Temperature Display Accuracy
±0.1℃
Temperature Display Accuracy@55℃
±0.3℃
Temperature uniformity@55℃
<0.3℃
Max. Heating/Cooling Rate
5℃/Sec
Gradient Temperature Setting Range
30-99℃
Gradient Range
1-42℃
Adapter block material
Aluminum
Display
7" LCD 800x480
Input
Touch panel
User defined file system
Max.30 segments 99 cycles, and storage for over 200 files.
Power off protection
Yes
Voltage,Frequency
100-120V/200-240V,50/60Hz cTUVus
Dimension[WxDxH]
280x370x250mm
Weight
11kg

Options :
0.36mL 96-Well Deep Well Plate, V-Bottom, round well, non-sterile
0.5mL 96-Well Deep Well Plate, V-bottom, round well, non-sterile
0.5mL 96-Well Deep Well Plate, V-bottom, round well, sterile
1.0mL 96-Well Deep Well Plate, U-bottom, round well, non-sterile
Length and width of the deep well plate comply with the SBS international standards
Depth of wells is increased based on the appearance and Volume of normal plates (mainly 96-well and 384-well plates) to enlarge the volume of each well
Manufacturing material (currently mostly used is polypropylene (PP)) is changed and surface treatment process has been improved for this series of deep well plates to adapt to its specific use range
Deep well plates of NEST have a variety of specifications, conforming with the needs of f µLly automatic workstations and experiments

1. Sample storage : can replace the conventional 1.5mL centrif µge tube to store samples, can be arranged tidily to save space, with large storage capacity, and can withstand the -80℃ refrigerator condition. Therefore, it’s also called storage plate.
2. Sample processing : can be used in combination with m µLti-pass pipettes, high-thro µghput automatic liquid processors and respective software to allow the high-thro µghput operation of biological samples (ex. protein precipitation, liquid extraction, nucleic acid extraction, etc). Greatly improve the efficiency of sample processing. Can withstand high temperature and high-pressure sterilization at 121℃.
3. Sample injection : suitable for the automatic devices of various companies, it can be directly placed in the sample compartment of the automatic device for injection. Compared to conventional sample injection, it can not only double the sample amount placed in the sample compartment, but also recognizes the direct sample injection of samples after processing on the 96-well plate, eliminating the tedious work of pipetting and placing samples back and forth.
Application
Genomic DNA extraction, plasmid DNA extraction, and nucleic acid extraction and purification of various samples
High-thro µghput automatic liquid operation to achieve high-thro µghput operations, such as protein precipitation, liquid extraction, and processing of animal tissues, bacteria, plants, soil, clinical samples, yeasts, etc
Material
USP VI polypropylene material
High chemical stability
Features
Temperature range : -80°C to 120°C
Autoclavable
Centrif µgal strength up to 3000g
Compatible with m µLti-channel pipette and automatic equipment
Optimized bottom design to minimize residual volume
Clear alphanumeric codes for easy identification
Conform to SBS/ ANSI
Specific 96-well deep plate used in nucleic acid extraction
Stackable, reliable tight sealing
Non-pyrogenic, DNase/RNase free

Individually wrapped
V-bottom
Suitable for suspension c µLtures or microbial c µLtures

Individually wrapped
U-bottom
Suitable for suspension c µLtures or microbial c µLtures

96-well
Polystyrene
µLtra-low attachment surface
Round bottom with lid
RNase-/DNase-free, Nonpyrogenic
Sterile

96-well
Polystyrene
µLtra-low attachment surface
Flat bottom with lid
RNase-/DNase-free, Nonpyrogenic
Sterile
1pc/bag, 24bags/case

Polystyrene
- Tissue C µLture Treated
- Flat Bottom with Clear Lid
- DNase-/RNase-Free
- Nonpyrogenic
- Sterile
1pcs/bag, 100bags/case

Polystyrene
- Tissue C µLture Treated
- Flat Bottom with Clear Lid
- DNase-/RNase-Free
- Nonpyrogenic
- Sterile
1pcs/bag, 100bags/case

30% OFF list price as part of our FALL Sale! On now until October 18th, 2024!
White polystyrene
Clear, flat bottom for luminescence assays (including chemiluminescence)
Tissue c µLture (TC)-treated surface
Sterilized
Clear lid
Suitable for microscopic observations/assays

Treated Surface for Adherent C µLture
Individually wrapped (100pcs/case)
Sterilized by gamma irradiation
DNAase & RNase-free
Sterile, non-pyrogenic
Made with polystyrene.

Non-treated Surface for Adherent C µLture
Individually wrapped (200pcs/case)
Sterilized by gamma irradiation
DNAase & RNase-free
Sterile, non-pyrogenic

30% OFF list price as part of our FALL Sale! On now until October 18th, 2024!
Black polystyrene
Clear, flat bottom for fluorescent assays
Tissue c µLture (TC)-treated surface
Sterilized
Clear lid
Suitable for microscopic observations/assays

96 Well 0.2ml Double Colour F µLl Skirt PCR Plate
GeneBio Systems’ 96 well 0.2ml double colour f µLl skirt PCR plate are manufactured from virgin, medical grade polypropylene and certified free from DNase, RNase and pyrogen. Made in a factory certified to ISO 13485

Specification : 0.2ml, double colour (white plate and clear wells)

Application : Suitable for end point PCR the gradient PCR instrument and the fluorescence quantitative PCR instrument.

Volume : 96 preps per kit.
The kit can be integrated with an automatic nucleic acid extractor, such as KingFisher, for high-thro µghput extraction experiments, or manually operated with a magnetic separation rack.
The purification system uses superparamagnetic nano-magnetic particles as the matrix, which can adsorb nucleic acids specifically thro µgh hydrogen bonds and static electricity under the condition of high concentration of leachate, while proteins and other non-specific impurities are removed by washing. Finally the nucleic acid are eluted with low salt buffer or RNase-free ddH2O. The purified nucleic acid can be used for various routine operations, including RT-PCR, RT-qPCR, fluorescence quantitative PCR (qPCR) and other downstream experiments.
Main components
The kit consists of the following components :
Component
Volume
Plate-A (Lysis Buffer/Mag Beads)
622µl/well
Plate-B (Wash Buffer)
600µl/well
Plate-C (Wash Buffer)
600µl/well
Plate-D (Elution Buffer)
50µl/well
Proteinase K
1mL × 2
Magnetic Head
1 pc
Prepare 1× PBS solution, pH 7.4, in case of need.
Storage conditions
The kit can be stored for 12 months at room temperature (15-25°C) under dry conditions.
Notes
1. Avoid repeated freezing-thawing of samples, otherwise the extracted viral RNA will be degraded and the extracted amount will decrease. The samples can be extracted immediately or stored at 4°C for testing for no more than 24 hours. Long-term storage can be placed at -20°C or -80°C.
2. All operating procedures, if not specified, are carried out at room temperature (15-25°C).
3. When using this kit, please wear lab coat, disposable latex gloves, disposable masks and use RNase-free consumables to avoid RNase pollution to the greatest extent. Prepare your own RNase-free pipette tips, etc.
4. Please read the instructions caref µLly before use and follow the instructions strictly. Clinical samples sho µLd be carried out in the µLtra clean table or biosafety cabinet.
5. There may be residual magnetic beads during elution, magnetic beads sho µLd be avoided as far as possible when pipetting samples.
6. The virus has a strong ability to infect, a variety of defense measures must be done before the operation. Proper disposal of samples and reagent materials, thoro µgh cleaning and disinfection of the operating table.
Sample preparation
A. Throat swab (with preservation solution), saliva : vortex vigorously for 30 sec, take 200 µL for experiment.
B. Plasma, serum and viral stock solution : prepare 10-200µl of plasma, serum or viral stock solution, if the initial amount is less than 200 µl, use PBS solution to make up to 200 µl.
C. Virus-infected tissue : prepare 10mg of virus-infected tissues to be ground with liquid nitrogen, and add 200µl of PBS solution to the ground tissues.
Protocol : Automatic Operation Process of 96 Deep-Well Plate
1. Take out the pre-packaged 96 deep-well plates.
2. Oscillate four angles of the Plate-A to make the Mag Beads suspended.
3. Open the sealing membranes of the 96 deep-well plates.
4. Add 20 µl Proteinase K and 200µl sample to each well of the Plate-A.
5. Place the Magnetic Head into the Plate-C.
6. Follow the instructions to put the 4 pre-packaged plates into the correct position of the machine.
7. Run the viral nucleic acid extraction program of magnetic bead method “gdsbio_normal_96.bdz”, or refer to the “Sheet of Program Design” below.
8. At the end of the automation process, in the Plate-D is the DNA/RNA solution, sealed with a sealing membrane and stored at -20°C or -80°C.
Sheet of Program Design
Plate
Operation Process
A
Mixing at 20~55°C for 10 min by vibrating, and the digested sample release DNA/RNA to the Mag Beads. Incubate for 2 min.Tansfer the beads to Plate-B.
B
Wash the beads by vibrating for 2 min, then tansfer the beads to Plate-C.
C
Wash the beads by vibrating for 2 min, dry the beads for 2 min, then tansfer the beads to Plate-D.
D
Elute the beads by vibrating for 2 min, then tansfer the beads back to Plate-C.
Suitable Instruments
Thermo KingFisher Flex96,

15-50% OFF list price as part of our FALL Sale! On now until October 18th, 2024!
Volume-based automatic saving-
Buy 10 x 500 pcs package, get $74.96 per 500 pcs package, or 15% saving

Quantity : 10/bag; 50 bags per carton (500 per carton )
•Made of medical grade polystyrene, high transparency, easy to observe experimentally.
•Available in three Volumes, uniform wall thickness, smooth and resistant to damage.
•Three venting holes on the dish for easy gas exchange.
•The bottom of the dish is designed to be more stable.

Can be used to store sample tubes, cryo tubes, and vials in freezers (-80°C, -20°C), fridges or at room temperature
Accommodates 2 mL snap-on tubes, 2 mL screw-cap tubes, 1.5 mL snap-on tubes, 1.5 mL screw-cap tubes and 2 mL cryogenic tubes
NOT autoclavable
